Rosières en Santerre France
28.1 tonnes of saturated steam per hour from wood chips. The biomass heating plant supplies a food industry production site.
19.9 MW
Thermal input, reciprocating grate
28.1 t/h
Steam output
Challenge
Process steam from wood chips was to be provided for a food production plant.
Solution
A mechanical grate firing with fly ash recirculation supplies a combined water-tube and fire-tube steam generator. Economiser, flue gas cleaning and glass-tube heat exchanger complete the plant.
Result
The plant was commissioned in December 2012. The combustion air is preheated with recovered flue gas heat.
Technology
Technology
Rosières en Santerre, France
- Fuel
- Wood chips
- Calorific value range
- 1.9–3.1 kWh/kg
- Annual fuel demand
- approx. 65,000 t
- Thermal input, reciprocating grate
- 19.9 MW
- Steam output
- 28.1 t/h
- Steam temperature
- 207 °C
- Steam pressure
- 18 bar (a)
- Feed water temperature
- 105–130 °C
- Operating permit (per brochure)
- Arrêté du 23 juillet 2010
