District heating and electricity from regional wood chips. A thermal oil heater supplies 5.135 MW for the energy supply in Bad Mergentheim.
6.43 MW
Thermal input, reciprocating grate
0.95 MW
Electrical output
4.095 MW
Process heat output
Challenge
A municipal energy supplier planned to supply public buildings and private households via a district heating network of around 5.5 kilometres.
Solution
Grate and afterburning chamber are combined with a two-part thermal oil heater. A split system and a finned-plate heat exchanger use the flue gas heat; an electrostatic precipitator cleans the flue gases.
Result
Commissioned in 2012, the biomass CHP plant provides district heating and electrical energy.
Technology
Technology
Bad Mergentheim, Germany
- Fuel
- Wood chips
- Calorific value range
- 1.7–3.5 kWh/kg
- Annual fuel throughput
- approx. 25,000 t
- Thermal input, reciprocating grate
- 6.43 MW
- Electrical output
- 0.95 MW
- Process heat output
- 4.095 MW
- Thermal oil output
- 5.135 MW
- Flow temperature
- 310 °C
- Return temperature
- 130 °C
- Operating permit (per brochure)
- 4. BImSchV
